Main technical data---Spiral tube forming machine |
|
|
Diameter Range |
80-1500mm |
|
Maximum Tube Length |
Unlimited mm |
|
Thickness of Strip |
0.4-1.5mm |
|
Width of Strip |
137mm |
|
Strip Speed |
1-40m/min |
|
Suitable Material |
Aluminum, Stainless steel, Galvanized steel,etc |
|
Dimension (L x W x H) |
2350mm x 2200mm x 2580mm |
|
Weight |
1800kg |
|
Main Motor Power |
11kW |
|
Cutting Motor Power |
5.5kW |
|
Air Pressure |
0.5-0.7Mpa |
